Product Details:
|
| Material: | Polyurethane MDI | Color: | Red |
|---|---|---|---|
| Dimensions: | 1040*700mm | App Size: | 0.075mm,0.1mm,0.15mm,0.18mm,0.25mm Etc |
| Hardness: | 85+/-2 Shore A | Application: | Ore, Coal Screening |
| Highlight: | 1040mm Polyurethane Screen Mesh,Vibrating Screen Mesh Polyurethane,700mm Polyurethane Screen Mesh |
||
As a core part of fine mesh vibrating screen, high frequency polyurethane screen mesh directly affect the screening efficiency and screening performance. It increases the mineral recovery rate, widely applied in metal and non-metallic minerals processing applications. This screen panels offer high open area and anti-blinding properties with performance that conventional woven wire screen cannot compare with
Features &Advantages
Technical Data
|
Material |
Polyurethane |
|
Aperture size(width) |
0.075mm - 1.5mm |
|
Aperture size(length) |
2.59mm - 8.2mm |
|
Life |
6 month - 12 month |
|
Color |
orange, red and as your requests |
|
Open area |
20.0% - 40.6% |
|
Hook |
polyurethane or metal |
|
Screen size |
700mm x 1040mm is common , other size can be design as your request |
