Product Details:
|
| Appearance: | Polyol IsMilky White Liquid | Color: | ISOCYNATE Is Brown |
|---|---|---|---|
| Flash Point: | High | Odor: | Very Low |
| Product Name: | Polyol And Isocyanate For The Air Filter | Storage Temperature: | Cool And Dry Place |
| Viscosity: | Low | DG Or NON DG: | NON DG |
| Highlight: | isocyanate and polyol for air filter,Isocyanate And Polyol For Air Filter,Low Odor Isocyanate And Polyol |
||
Polyol and Isocynate for the air filter
JYLQ－01A/B
Introduction:
JYLQ-01A is made up of polymer polyol, grafted polyether polyol, cross linker, blowing agent, and composite catalyst. JYLQ-01B is made up of modified MDI. This system has good liquidity with easy
process. This system is applied to produce the air filter for the car or other industry facility.
Typical Properties
| Item Unit | JYLQ-01A | JYLQ-01B | |
|
Appearance NCO Viscosity(25℃)Density (20℃) Storage temp. Shelf life |
% mpa.s g/ml ℃ Months |
Milky white liquid / 1200±300 1.05±0.05 15－25 12 |
Brown liquid 29.4±1 100±30 1.20±0.05 15－25 12 |
Recommended ratio
| Weight ratio | |
|
JYLQ-01A JYLQ-01B |
100 30-40 |
REACTIVE PROPERTY (Material temperature is 25℃)
| By hand | Machine | ||
|
Cream time (s) Gel time (s) Mold temperature (℃) Demould time (min)FRD (kg/m3) |
s s ℃ min kg/m3 |
55-60 70-80 35-55 8-10 350-400 |
9-10 65-75 35-55 8-10 350-400 |
TYPICAL PHYSICAL PROPERTY
| Unit | Data | |
|
Moulded density Tensile strength Elongation (%) Tear strength Hardness |
Kg/m3 Kpa % N/cm Shore A
|
400 ≥80 ≥130 ≥3.2 25-45 |
The final interpretation of this specification is owned by our company.
